Why Gas Station Properties Present Unique ALTA Survey Challenges
A gas station is not like a strip mall or an office building. Fuel tanks sit underground. Pumps sit close to the road. Canopies stretch out over parking areas. All of this makes an ALTA survey on a fuel station harder to get right than on most commercial sites.
If you are buying, financing, or refinancing a gas station, here is what a surveyor runs into on this type of property, and why it can take longer than a typical retail parcel.
Petroleum Tanks Complicate What Table A Item 11 Can Actually Show
Table A Item 11 asks a surveyor to plot underground utilities. On a gas station, that means product lines, vent pipes, and the tanks themselves, all packed close together near the pump islands.
This tight spacing makes it hard for a private utility locator to get a clean read. Signals from one line can bleed into another. Old piping sometimes still sits in the ground next to active lines, and it does not always show up the same way on a location.
If a Phase I Environmental Site Assessment is already underway, get the surveyor and the environmental consultant talking to each other early. Tank and piping records from that assessment can save the surveyor time in the field, and a clear picture of what sits below ground keeps the whole deal moving.
Kentucky UST Registration Records Can Create Boundary and Easement Conflicts
Every regulated underground storage tank has to be registered with the Kentucky Energy and Environment Cabinet’s Division of Waste Management. This falls under KRS 224.60-105 and 401 KAR Chapter 42.
A surveyor pulls these records and checks them against what is actually in the ground. Sometimes a tank listed as closed or removed is still sitting there, just filled with sand or foam instead of fuel. If that tank happens to sit near a boundary line or inside a recorded easement, it becomes a real problem for the new owner. Excavation, construction, or even a new fence line can run into it.
This is one reason a fuel station survey often takes a closer look at old registration filings than a typical commercial site would.
Canopy Columns and Fuel Dispenser Islands Frequently Encroach Setback and Easement Lines
Canopies get built for visibility. Owners want drivers to see the price sign and pull in without slowing down much. That often means the canopy sits close to the road, sometimes right up against a setback line or a right-of-way.
Dispenser islands run into similar problems. They get placed for traffic flow first, and recorded easements second. A survey will often catch a canopy column standing inside a utility easement, or a dispenser island that crosses a setback line most people never thought to check.
These are physical facts, not legal conclusions. A survey shows where things sit. A real estate attorney or title company decides what that means for the deal.
Access and Curb-Cut Rights Are Especially High-Stakes for Gas Stations
A gas station lives or dies on visibility and easy access. If a driver cannot turn in without slowing down, or cannot turn in at all, the site loses value fast.
Curb cuts along Kentucky state routes fall under the control of the Kentucky Transportation Cabinet. Any change to an existing curb cut, or plans for a new one, has to go through that process. An ALTA survey plots these access points along with any recorded ingress and egress easements tied to the property.
Buyers should check this closely before closing. A restricted or reduced curb cut can cut into daily traffic count, and that cuts into the money the business on that lot brings in.
Environmental Site Conditions Can Alter the Survey’s Scope and Timeline
A site with a known release history, monitoring wells, or a vapor recovery system needs more than the standard Table A items checked off. These features have to be located and shown accurately, and that takes more time in the field.
If the property has an open case with the Division of Waste Management, expect the survey to take longer. The surveyor may need to coordinate with an environmental firm already on site, and a title company may hold off on removing certain exceptions until that environmental picture is clear.
None of this means the deal falls apart. It just means the timeline stretches out a bit, so buyers should plan for that instead of getting caught off guard.
Frequently Asked Questions
Does a closed or removed underground storage tank still need to appear on an ALTA survey?
Yes. Surveyors look for signs of a former tank, such as fill ports, vent stubs, or patched pavement, even after the tank has been formally closed. These spots can still affect digging or new construction later, so they get noted on the survey.
Why do gas station ALTA surveys in Kentucky sometimes take longer than other commercial properties?
The extra time usually comes from coordinating with the private utility locator around congested fuel lines, plus checking Kentucky Division of Waste Management UST registration records against what is actually on site.
Can an ALTA survey identify unresolved environmental liabilities on a former fuel station site?
No. An ALTA survey is not an environmental report. It shows physical evidence and recorded documents on the ground. Actual contamination has to be confirmed through a Phase I or Phase II Environmental Site Assessment done by an environmental professional.
Do canopy structures count toward Table A Item 7 (exterior building dimensions)?
Not always. Canopies, kiosks, and car wash buildings are often handled separately from the main building footprint. Buyers should confirm this with the surveyor before ordering the survey, so nothing gets left out of scope.
Are curb cuts and highway access points shown on a standard boundary survey, or only on an ALTA survey?
An ALTA survey covers this in more depth. Table A items call for recorded easements and access rights to be researched and plotted, which goes beyond what a basic boundary survey typically includes.
